Yamaha SPORT HERITAGE XSR 900 ABARTH 2016
Add model to garageEMBRAGUE Yamaha XSR 900 ABARTH 2016
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
PRIMARY DRIVEN GEAR COMP.
1WS161500000
|
821,02 € | 1 | Add |
| 2 |
PLATE, THRUST
363161540000
|
11,56 € | 1 | Add |
| 3 |
MAINTENANCE PART
1WS163710100
|
328,16 € | 1 | Add |
| 4 |
PLATE, FRICTION
5VY163210000
|
20,23 € | 1 | Add |
| 5 |
DISCO, DE EMBRAGUE
5VY163252000
|
17,36 € | 1 | Add |
| 6 |
PLATE, FRICTION
5TG163210000
|
15,83 € | 1 | Add |
| 7 |
PRESSURE PLATE ASSY
1WS163500000
|
109,09 € | 1 | Add |
| 8 |
BRG,R-B 6001 28MM 28G KY
933060010500
|
16,78 € | 1 | Add |
| 9 |
SPRING, COMPRESSION(3GM)
90501230E400
|
5,50 € | 1 | Add |
| 10 |
BOLT, WITH WASHER
901190626300
|
3,62 € | 1 | Add |
| 11 |
SPACER 1
1WS161810000
|
38,22 € | 1 | Add |
| 12 |
BEARING
93310232R900
|
31,15 € | 1 | Add |
| 13 |
PLATE, THRUST
363161540000
|
11,56 € | 1 | Add |
| 14 |
WASHER, PLATE
902012003000
|
8,59 € | 1 | Add |
| 15 |
WASHER, CONICAL SPRING
902082000100
|
17,22 € | 1 | Add |
| 16 |
NUT
901792000700
|
17,52 € | 1 | Add |
| 17 |
ROD, PUSH 1
1WS163560000
|
36,15 € | 1 | Add |
| 18 |
PALANCA DE EMPUJE COMPLETA
1WS163400100
|
40,76 € | 1 | Add |
| 19 |
SPRING, TORSION
905081813200
|
3,09 € | 1 | Add |
| 20 |
WASHER, PLATE
902011002900
|
1,60 € | 1 | Add |
| 21 |
CIRCLIP(10W)
990091040000
|
0,62 € | 1 | Add |
