Yamaha 125cc XVS125 DRAG STAR 2002
Add model to garageELECTRIC EQUIPMENT 1 Yamaha XVS125 DRAG STAR 2002
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
RECTIFIER & REGULATOR ASSY
4XY819600000
|
267,12 € | 1 | Add |
| 2 |
BOLT, FLANGE
958170602500
|
4,93 € | 1 | Add |
| 3 |
WASHER, PLATE(3MB)
902020518700
|
0,65 € | 1 | Add |
| 4 |
NUT, SPRING(4ES)
901830606900
|
1,97 € | 1 | Add |
| 5 |
STARTER RELAY ASSY (RC19-015)
4SV819401200
|
103,52 € | 1 | Add |
| 6 |
FUSE (12V 30A)
1AE821510000
|
2,30 € | 10 | Add |
| 7 |
BOLT, SMALL FLANGE
950270600800
|
0,38 € | 1 | Add |
| 8 |
BATTERY (YTZ7S)
5TJ821000100
|
125,23 € | 1 | Add |
| 9 |
BAND, BATTERY
133821310000
|
13,79 € | 1 | Add |
| 10 |
CABLE CONDUCTOR POSITIVO
5JX821150000
|
Obsolete | 1 | Not available |
| 11 |
WIRE, MINUS LEAD
5JX821160000
|
22,48 € | 1 | Add |
| 12 |
MAIN SWITCH STEERING LOCK
4VR825010100
|
604,42 € | 1 | Add |
| 13 |
SCREW
901490800200
|
2,34 € | 1 | Add |
| 14 |
WIRE HARNESS ASSY
5JX825900000
|
Obsolete | 1 | Not available |
| 15 |
FUSE (12V 15A)
36Y821510000
|
4,35 € | 1 | Add |
| 16 |
FUSE (10A)
42X821510000
|
5,74 € | 10 | Add |
| 17 |
IGNITOR UNIT ASSY
5JX823050000
|
Obsolete | 1 | Not available |
| 18 |
RIVET
902690700100
|
1,63 € | 1 | Add |
| 19 |
HEATER ASSY
5FU837902000
|
48,18 € | 1 | Add |
| 20 |
TERMINAL 1
5FU821030000
|
3,43 € | 1 | Add |
| 21 |
WASHER, PLATE
902010801600
|
2,26 € | 1 | Add |
| 22 |
RELE DE DESTELLADOR COMPL.
3GM833500200
|
110,13 € | 1 | Add |
| 23 |
RELAY ASSY (5JX-00)
5JX819500000
|
96,19 € | 1 | Add |
| 24 |
THERMO SWITCH ASSY
4TR825600000
|
Obsolete | 1 | Not available |
| 25 |
BAND
1UA825910000
|
2,03 € | 5 | Add |
| 26 |
CLAMP(4FM)
904641519500
|
2,40 € | 1 | Add |
| 27 |
CLAMP(4FM)
904641519500
|
2,40 € | 1 | Add |
