Yamaha 50cc MARCHAS DT50X 2010

Add model to garage

WATER PUMP Yamaha DT50X 2010

Pos. Ref./Description Price Qty.
1 EJE IMPULSOR COMPLETO
1HDE24500000 2VRE24500000
55,13 € 1 Add
2 RETEN DE ACEITE
931031081200
8,83 € 1 Add
3 PIN, DOWEL
9360322X0000
0,30 € 10 Add
4 WASHER, PLATE
9020108X1000
0,71 € 10 Add
5 CIRCLIP
9341008X0000
0,30 € 10 Add
6 GEAR, IMPELLER SHAFT
3NCE24590000
10,26 € 1 Add
7 COVER, HOUSING
13CE24220000
47,83 € 1 Add
8 PIN, DOWEL
9360410X0000
0,56 € 10 Add
9 GASKET, HOUSING COVE
3NCE24280000 3NCE24280100
0,75 € 10 Add
10 BOLT, HEXAGON SOCKET HEAD(M01)
9011006X7500 9131N0605500
2,03 € 10 Add
11 BOLT, HEXAGON SOCKET HEAD(M01)
9011006X7700 9011006X0400
1,16 € 10 Add
12 WASHER, PLATE(61A)
9020106X0900
0,74 € 10 Add
13 JOINT, HOSE 2
4YVE25820000
5,74 € 1 Add
14 O-RING
9321012X0000
0,93 € 1 Add
15 BOLT, HEXAGON SOCKET HEAD(M01)
9011006X8200 9011006X2100
1,36 € 10 Add
