Yamaha 50cc MARCHAS DT50X 2010
Add model to garageWATER PUMP Yamaha DT50X 2010
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
EJE IMPULSOR COMPLETO
1HDE24500000
|
71,07 € | 1 | Add |
| 2 |
RETEN DE ACEITE
931031081200
|
11,89 € | 1 | Add |
| 3 |
PIN, DOWEL
9360322X0000
|
0,41 € | 10 | Add |
| 4 |
WASHER, PLATE
9020108X1000
|
0,86 € | 10 | Add |
| 5 |
CIRCLIP
9341008X0000
|
0,41 € | 10 | Add |
| 6 |
GEAR, IMPELLER SHAFT
3NCE24590000
|
13,09 € | 1 | Add |
| 7 |
COVER, HOUSING
13CE24220000
|
Obsolete | 1 | Not available |
| 8 |
PIN, DOWEL
9360410X0000
|
0,62 € | 10 | Add |
| 9 |
GASKET, HOUSING COVE
3NCE24280000
|
0,85 € | 10 | Add |
| 10 |
BOLT, HEXAGON SOCKET HEAD(M01)
9011006X7500
|
2,76 € | 10 | Add |
| 11 |
BOLT, HEXAGON SOCKET HEAD(M01)
9011006X7700
|
1,54 € | 10 | Add |
| 12 |
WASHER, PLATE(61A)
9020106X0900
|
Obsolete | 10 | Not available |
| 13 |
JOINT, HOSE 2
4YVE25820000
|
Obsolete | 1 | Not available |
| 14 |
O-RING
9321012X0000
|
Obsolete | 1 | Not available |
| 15 |
BOLT, HEXAGON SOCKET HEAD(M01)
9011006X8200
|
1,72 € | 10 | Add |
