Yamaha 50cc SCOOTERS Bw's 50 2001
Add model to garageFUEL TANK Yamaha Bw's 50 2001
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
FUEL TANK COMP.
4VPF41101033
|
Obsolete | 1 | Not available |
| 2 |
NUT, FLANGE(4MV)
957070650000
|
5,60 € | 1 | Add |
| 3 |
FUEL COCK ASSY 1
4CWF45001000
|
67,18 € | 1 | Add |
| 4 |
O-RING
4CWF452K1000
|
6,58 € | 1 | Add |
| 5 |
SCREW 256241430000
901490601100
|
3,60 € | 10 | Add |
| 6 |
WASHER, PLATE(3MB)
902020518700
|
0,62 € | 1 | Add |
| 7 |
PIPE, FUEL 1
4VPF43110000
|
9,20 € | 1 | Add |
| 8 |
SPRING, COMPRESSION
905010886800
|
2,64 € | 1 | Add |
| 9 |
CLIP
90467090A200
|
0,74 € | 1 | Add |
| 10 |
CAP ASSY
4VPF46100200
|
18,27 € | 1 | Add |
| 11 |
LABEL, CAUTION
4VPF415A0000
|
Obsolete | 1 | Not available |
| 12 |
COVER, FILLER
4VPF414A2000
|
Obsolete | 1 | Not available |
| 13 |
BOSS, CONNECTOR
4TEF17530000
|
Obsolete | 1 | Not available |
| 14 |
HOSE
91A100705600
|
5,46 € | 1 | Add |
| 15 |
CLIP
90467090A200
|
0,74 € | 1 | Add |
| 16 |
HOSE
90445078A300
|
2,29 € | 5 | Add |
| 17 |
HOSE (L1040)
9044510MA900
|
54,87 € | 1 | Add |
