Yamaha CUSTOM VIRAGO XV250 2004
Add model to garageFENDER Yamaha VIRAGO XV250 2004
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
FRONTAL DEFENSA COMP.
3LV2151001P1
|
155,85 € | 1 | Add |
| 2 |
BOLT, FLANGE(2UJ)
950240801200
|
2,01 € | 1 | Add |
| 3 |
HOLDER,WIRE 1
4DN215970100
|
Obsolete | 1 | Not available |
| 4 |
FLAP, FRONT FENDER
3LV215210000
|
49,21 € | 1 | Add |
| 5 |
SCREW, BINDING
989070401000
|
1,46 € | 1 | Add |
| 6 |
WASHER, PLATE (34L)
90201043H700
|
3,89 € | 1 | Add |
| 7 |
NUT, CAP
953070480000
|
0,75 € | 1 | Add |
| 8 |
REAR FENDER COMP.
3LV2161000P1
|
457,85 € | 1 | Add |
| 9 |
SEAL 2
2UJ217350000
|
1,54 € | 5 | Add |
| 10 |
SEAL 4
3DM2173N0000
|
2,01 € | 5 | Add |
| 11 |
SEAL 3
2UJ2173M0100
|
4,49 € | 1 | Add |
| 12 |
EMBLEM, YAMAHA
992460008000
|
22,76 € | 1 | Add |
| 13 |
BOLT, FLANGE
958171002000
|
2,43 € | 1 | Add |
| 14 |
REINF. COMP.
2UJ216703000
|
124,60 € | 1 | Add |
| 15 |
BOLT, BUTTON HEAD(3LS)
920141005000
|
5,40 € | 1 | Add |
| 17 |
958-69527-00 WASHER, PLAIN
929901020000
|
1,60 € | 1 | Add |
| 18 |
NUT (22F)
901791039400
|
4,49 € | 1 | Add |
| 19 |
BRACKET, REFLECTOR
2UJ216410000
|
15,91 € | 1 | Add |
| 20 |
SCREW, PAN HEAD(3LA)
985170501000
|
0,62 € | 1 | Add |
| 21 |
WASHER(1RW)
929070560000
|
0,62 € | 1 | Add |
| 22 |
NUT, CAP
953070580000
|
1,30 € | 1 | Add |
| 23 |
GROMMET (438)
904801506100
|
4,49 € | 1 | Add |
| 24 |
REAR STAY COMP.
3LU216400000
|
722,18 € | 1 | Add |
| 25 |
GROMMET 152845180000
904801201300
|
2,76 € | 1 | Add |
| 26 |
GROMMET, SEAT HANDLE
1J3247420000
|
4,65 € | 1 | Add |
