Yamaha FZ- SERIES FZ1 Fazer ABS 2012
Add model to garageELECTRIC EQUIPMENT 3 Yamaha FZ1 Fazer ABS 2012
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
HYDRAULIC UNIT ASSY
5D0859300900
|
2.742,91 € | 1 | Add |
| 2 |
PLUG, DRAIN
5CG241960000
|
69,12 € | 1 | Add |
| 3 |
HOSE (L450)
904451014400
|
6,09 € | 1 | Add |
| 4 |
BRACKET 1
5D02175T0000
|
Obsolete | 1 | Not available |
| 5 |
DAMPER 2
5YU216390000
|
0,52 € | 1 | Add |
| 6 |
BRACKET 2
5D02175U0000
|
193,78 € | 1 | Add |
| 7 |
SEAL
5SL212680000
|
2,48 € | 1 | Add |
| 8 |
SEAL
1B3283071000
|
2,33 € | 1 | Add |
| 9 |
BOLT, FLANGE
958170601200
|
0,22 € | 1 | Add |
| 10 |
NUT, CROWN
901760600800
|
1,46 € | 1 | Add |
| 11 |
MOLD, FUEL TANK
5YU241880000
|
5,07 € | 1 | Add |
| 12 |
COVER
5D02172W0000
|
62,19 € | 1 | Add |
| 13 |
RIVET(4PH)
902690707700
|
1,60 € | 1 | Add |
| 14 |
ELECTRONIC CONTROL UNIT ASSY
5D0859400000
|
1.741,60 € | 1 | Add |
| 15 |
BAND, BATTERY
26L821310000
|
6,49 € | 1 | Add |
| 16 |
CONNECTOR
3YA823780000
|
18,40 € | 1 | Add |
| 17 |
CONJUNTO DE CABLES
5D0859700100
|
184,11 € | 1 | Add |
| 18 |
HOLDER, WIRE
5D0238740000
|
11,08 € | 1 | Add |
| 19 |
HOLDER STOPPER 1
5D0233580000
|
20,62 € | 1 | Add |
| 20 |
BOLT, BUTTON HEAD(4NK)
920140601400
|
0,93 € | 1 | Add |
| 21 |
CLAMP
904641400300
|
20,34 € | 1 | Add |
| 22 |
CLAMP
904641201300
|
2,55 € | 1 | Add |
| 23 |
CONJUNTO DE CABLES
5D0859800100
|
177,88 € | 1 | Add |
| 24 |
BOLT, BUTTON HEAD(4NK)
920140601400
|
0,93 € | 1 | Add |
| 25 |
CLAMP
904641201300
|
2,55 € | 1 | Add |
| 26 |
RELAY ASSY (5JJ-20)
5JJ819502000
|
104,13 € | 1 | Add |
| 27 |
HOLDER, RELAY
5JJ819520000
|
8,49 € | 1 | Add |
