Yamaha MAXI SCOOTERS T-Max ABS 2011
Add model to garageHANDELBAR AND CABLES Yamaha T-Max ABS 2011
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
SPRING, RETURN
5VU253330000
|
6,82 € | 1 | Add |
| 2 |
PIN
902491200400
|
2,48 € | 1 | Add |
| 3 |
NUT
901790601800
|
1,37 € | 1 | Add |
| 4 |
HANDLE COMP.
4B5261101100
|
187,77 € | 1 | Add |
| 5 |
BOLT, FLANGE
901051015000
|
7,53 € | 1 | Add |
| 6 |
WASHER, PLATE
902011004300
|
1,46 € | 1 | Add |
| 7 |
NUT, U
956171010000
|
5,07 € | 1 | Add |
| 8 |
CLAMP(4GY)
904642019100
|
4,83 € | 1 | Add |
| 9 |
EMPUNADURA (MI)
4YR262410300
|
24,52 € | 1 | Add |
| 10 |
EMPUNADURA COMPLETA
4YR262400300
|
36,63 € | 1 | Add |
| 11 |
END, GRIP
3HX262461000
|
52,60 € | 1 | Add |
| 12 |
THROTTLE CABLE ASSY
4B5263011100
|
127,25 € | 1 | Add |
| 13 |
BOLT, BUTTON HEAD
920120501200
|
0,62 € | 1 | Add |
| 14 |
SCREW, PAN HEAD
985170502000
|
0,62 € | 1 | Add |
| 15 |
CLAMP(4HM)
904641519200
|
3,18 € | 1 | Add |
| 16 |
COVER, HANDLEBAR LOWER 1
4B5261440000
|
Obsolete | 1 | Not available |
| 17 |
SCREW, WITH WASHER
901590503200
|
0,41 € | 1 | Add |
| 18 |
COVER, HANDLEBAR UPPER 1
4B5261430000
|
105,99 € | 1 | Add |
| 19 |
COVER, HANDLEBAR UPPER 2
4B5261450000
|
40,91 € | 1 | Add |
| 20 |
NUT, SPRING(8AJ)
901830506800
|
1,54 € | 1 | Add |
| 21 |
SCREW, TAPPING
901670507900
|
3,60 € | 5 | Add |
| 22 |
NUT, SPRING(1YT)
901830504200
|
0,62 € | 5 | Add |
| 23 |
WIRE
4B52835X0100
|
106,94 € | 1 | Add |
| 24 |
CLAMP(4HM)
904641519200
|
3,18 € | 1 | Add |
| 25 |
GUIDE, CABLE 1
4B5261310000
|
12,50 € | 1 | Add |
| 26 |
BOLT, FLANGE
958170601000
|
0,28 € | 1 | Add |
