Yamaha MAXI SCOOTERS X-Max 250 SPORT 2012
Add model to garageWATER PUMP Yamaha X-Max 250 SPORT 2012
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
WATER PUMP ASSY
1C0E24200100
|
109,81 € | 1 | Add |
| 2 |
IMPELLER SHAFT ASSY
1C0E24500000
|
73,88 € | 1 | Add |
| 3 |
COVER, HOUSING
4HC124220100
|
109,23 € | 1 | Add |
| 4 |
GASKET, HOUSING COVER 2
4HC124281000
|
15,44 € | 1 | Add |
| 5 |
BOLT,SOCKET
913170603500
|
1,42 € | 1 | Add |
| 6 |
BRG,R-B 6000 26MM 19G NT
93306000Y400
|
15,70 € | 1 | Add |
| 7 |
HOUSING, WATER PUMP
4HC124210000
|
190,70 € | 1 | Add |
| 8 |
OIL SEAL (J10)
931011009000
|
11,12 € | 1 | Add |
| 9 |
SEAL, MECHANICAL
1C0E24380000
|
27,34 € | 1 | Add |
| 10 |
CIRCLIP(10W)
990091040000
|
0,62 € | 1 | Add |
| 11 |
GASKET 256113960000
904300601400
|
2,33 € | 1 | Add |
| 12 |
BOLT, FLANGE
950220603500
|
0,69 € | 1 | Add |
| 13 |
O-RING
9321033X0100
|
0,34 € | 10 | Add |
| 14 |
DRIVE GEAR ASSY
1C0E25400000
|
26,32 € | 1 | Add |
| 15 |
WASHER, PLATE(61A)
9020110X1900
|
0,86 € | 1 | Add |
| 16 |
JOINT
4HC124460000
|
35,26 € | 1 | Add |
| 17 |
O-RING
9321015X0300
|
1,31 € | 10 | Add |
| 18 |
BOLT,SOCKET
913170601600
|
0,28 € | 1 | Add |
