Yamaha SPORT TOURING FJR1300A 2003
Add model to garageFRONT FORK Yamaha FJR1300A 2003
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 28 |
METAL, SLIDE 1
4SV231251000
|
22,34 € | 1 | Add |
| 29 |
SEAL, DUST
4SV231440000
|
21,57 € | 1 | Add |
| 30 |
OIL SEAL
4SV231450100
|
19,87 € | 1 | Add |
| 31 |
SEAT 1
4SV231150000
|
7,89 € | 1 | Add |
| 32 |
CLIP, OIL SEAL
4SV231560000
|
2,64 € | 1 | Add |
| 33 |
CYLINDER COMP., FRONT FORK
5JW231700000
|
Obsolete | 1 | Not available |
| 34 |
SPINDLE, TAPER
5LV231730000
|
50,99 € | 1 | Add |
| 35 |
BOLT, HEXAGON SOCKET HEAD
9011010N5200
|
8,44 € | 1 | Add |
| 36 |
GASKET (5R6)
904301017100
|
4,56 € | 5 | Add |
| 37 |
PLUNGER
5JW2318Y0000
|
6,24 € | 1 | Add |
| 38 |
SPRING, FRONT FORK
5VS231410000
|
Obsolete | 1 | Not available |
| 39 |
WASHER, PLATE (856)
902011032100
|
10,09 € | 1 | Add |
| 40 |
SPACER
5JW231180000
|
9,07 € | 1 | Add |
| 41 |
BOLT, CAP
5JW231110100
|
277,97 € | 1 | Add |
| 42 |
O-RING(4SV)
9321040N5000
|
4,28 € | 1 | Add |
| 43 |
KNOB (TEN)
5JW2319W0000
|
9,20 € | 1 | Add |
| 44 |
SCREW, OVAL HEAD
986800300800
|
2,76 € | 1 | Add |
| 45 |
NUT(6TD)
953371060000
|
6,37 € | 1 | Add |
| 46 |
COVER
4SV2331G0000
|
20,34 € | 1 | Add |
| 47 |
BOLT,SOCKET
913140804000
|
2,97 € | 1 | Add |
| 48 |
UNDER BRACKET COMP.
5JW233400000
|
Obsolete | 1 | Not available |
| 49 |
BOLT, SOCKET
913170802500
|
1,12 € | 5 | Add |
