Yamaha SPORT TOURING TDM 900 2008
Add model to garageCYLINDER HEAD Yamaha TDM 900 2008
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
CYLINDER HEAD ASSY
5PS111011000
|
2.477,48 € | 1 | Add |
| 2 |
GUIDE, INTAKE VALVE
3LD111331000
|
51,88 € | 1 | Add |
| 3 |
GUIDE, EXHAUST VALVE
3LD111341000
|
64,83 € | 1 | Add |
| 4 |
CIRCLIP (22F)
934401010900
|
1,54 € | 1 | Add |
| 5 |
PIN, DOWEL(3XW)
918081602300
|
1,60 € | 5 | Add |
| 6 |
PLUG, STRAIGHT SCREW (33M)
903401810100
|
11,55 € | 1 | Add |
| 7 |
BOLT, WASHER BASED (4H7)
901050615300
|
2,64 € | 1 | Add |
| 8 |
BOLT, STUD 3
956170862500
|
4,36 € | 1 | Add |
| 9 |
PLUG (31M)
903381015000
|
4,08 € | 1 | Add |
| 10 |
PLUG, SPARK (DPR8EA-9)
947010024100
|
4,54 € | 10 | Add |
| 10 |
PLUG, SPARK(X24EPR-U-9)
947010024200
|
10,15 € | 10 | Add |
| 11 |
WASHER, PLATE(3GM)
90201103M400
|
6,15 € | 1 | Add |
| 12 |
NUT
901791002600
|
12,67 € | 1 | Add |
| 13 |
BOLT, SOCKET
913170615000
|
11,36 € | 1 | Add |
| 14 |
BOLT, FLANGE(2UJ)
950240801200
|
2,01 € | 1 | Add |
| 15 |
WASHER, PLATE 3411117500
902010808700
|
3,18 € | 1 | Add |
| 16 |
GASKET, CYLINDER HEAD 1
5PS111810000
|
105,12 € | 1 | Add |
| 17 |
COVER, CYLINDER HEAD 1
5PS111901000
|
Obsolete | 1 | Not available |
| 18 |
PLATE, BREATHER
5PS111650000
|
35,84 € | 1 | Add |
| 19 |
GASKET, BREATHER COVER
5PS111690000
|
6,43 € | 1 | Add |
| 20 |
SCREW
901490501000
|
2,43 € | 1 | Add |
| 21 |
CAP, CASE
5PS148990000
|
52,79 € | 1 | Add |
| 22 |
PLATE
5PS1482K0000
|
4,29 € | 1 | Add |
| 23 |
REED VALVE ASSY
5PS148900000
|
52,74 € | 1 | Add |
| 24 |
BOLT, FLANGE(6U1)
950270602000
|
0,28 € | 1 | Add |
| 25 |
GASKET, HEAD COVER 1
5PS111930000
|
61,51 € | 1 | Add |
| 26 |
BOLT(4BP)
90109066F000
|
4,36 € | 1 | Add |
