Yamaha FZ- SERIES FZ1 ABS 2009

Add model to garage

GEAR SHIFT AND PEDAL Yamaha FZ1 ABS 2009

Pos. Ref./Description Price Qty.
1 HANGER, SPRING
5VY181440000
2,40 € 1 Add
2 HOOK, SPRING
132163460000
3,20 € 1 Add
3 STOPPER LEVER ASSY
5VY181400000
80,37 € 1 Add
4 COLLAR(4KN)
903870804S00
6,67 € 1 Add
5 STOPPER, SCREW
39P181270000 5VY181271000
18,41 € 1 Add
6 BEARING
933171129500
11,08 € 1 Add
7 SEAL, OIL (30X)
931021232100 931021210600
14,74 € 1 Add
8 CIRCLIP
990021060000
0,79 € 1 Add
9 WASHER, PLATE (353)
902011257500
2,82 € 1 Add
10 EJE SELECTOR COMPLETO
2D1181010200 2D1181010000
107,66 € 1 Add
11 SPRING, TORSION
905083214100 905083202000
5,29 € 1 Add
12 COLLAR
903871211D00
9,69 € 1 Add
13 ARM, SHIFT
39P181120000 2D1181120000
60,08 € 1 Add
14 BOLT, FLANGE
950220602000
0,51 € 1 Add
15 SHIFT PEDAL ASSY
2D1181100000
146,16 € 1 Add
16 COVER, SHIFT PEDAL
5EB181130000
16,94 € 1 Add
17 ROD, SHIFT
2D1181150000
13,02 € 1 Add
18 NUT (2H9)
901700622800
2,34 € 1 Add
19 NUT
9538R0670000 953040670000
0,45 € 1 Add
20 JOINT, ROD 1
5VX181160000
55,42 € 1 Add
21 COVER, DUST
5VX181540000
4,47 € 1 Add
22 BOLT, BUTTON HEAD
920120602000 901110609800
0,83 € 1 Add
