Yamaha FZ- SERIES FZ1 ABS 2009
Add model to garageGEAR SHIFT AND PEDAL Yamaha FZ1 ABS 2009
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
HANGER, SPRING
5VY181440000
|
2,33 € | 1 | Add |
| 2 |
HOOK, SPRING
132163460000
|
3,49 € | 1 | Add |
| 3 |
STOPPER LEVER ASSY
5VY181400000
|
84,96 € | 1 | Add |
| 4 |
COLLAR(4KN)
903870804S00
|
7,08 € | 1 | Add |
| 5 |
STOPPER, SCREW
39P181270000
|
19,40 € | 1 | Add |
| 6 |
BEARING
933171129500
|
11,60 € | 1 | Add |
| 7 |
SEAL, OIL (30X)
931021232100
|
14,71 € | 1 | Add |
| 8 |
CIRCLIP
990021060000
|
0,90 € | 1 | Add |
| 9 |
WASHER, PLATE (353)
902011257500
|
3,32 € | 1 | Add |
| 10 |
EJE SELECTOR COMPLETO
2D1181010200
|
107,47 € | 1 | Add |
| 11 |
SPRING, TORSION
905083214100
|
5,26 € | 1 | Add |
| 12 |
COLLAR
903871211D00
|
10,39 € | 1 | Add |
| 13 |
ARM, SHIFT
39P181120000
|
59,97 € | 1 | Add |
| 14 |
BOLT, FLANGE
950220602000
|
0,51 € | 1 | Add |
| 15 |
SHIFT PEDAL ASSY
2D1181100000
|
146,56 € | 1 | Add |
| 16 |
COVER, SHIFT PEDAL
5EB181130000
|
16,92 € | 1 | Add |
| 17 |
ROD, SHIFT
2D1181150000
|
13,76 € | 1 | Add |
| 18 |
NUT (2H9)
901700622800
|
2,59 € | 1 | Add |
| 19 |
NUT
9538R0670000
|
0,45 € | 1 | Add |
| 20 |
JOINT, ROD 1
5VX181160000
|
58,54 € | 1 | Add |
| 21 |
COVER, DUST
5VX181540000
|
4,75 € | 1 | Add |
| 22 |
BOLT, BUTTON HEAD
920120602000
|
0,71 € | 1 | Add |
