Yamaha MAXI SCOOTERS X-Max 250 ABS 2013
Add model to garageFRAME Yamaha X-Max 250 ABS 2013
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
FRAME COMP.
37PF11100100
|
1.609,46 € | 1 | Add |
| 2 |
ENGINE BRACKET COMP 2
2DMF14200000
|
90,66 € | 1 | Add |
| 3 |
COLLAR
9038710X0200
|
7,92 € | 1 | Add |
| 4 |
STAY ENGINE
5B2F14800000
|
32,84 € | 1 | Add |
| 5 |
BOLT, ENGINE MOUNTING
901051005600
|
23,56 € | 1 | Add |
| 6 |
WASHER, PLATE (4X7)
90201105A200
|
4,27 € | 1 | Add |
| 7 |
NUT, SELF-LOCKING(3KJ)
901851015400
|
3,65 € | 1 | Add |
| 8 |
BOLT FLANGE
9010512X0100
|
12,72 € | 1 | Add |
| 9 |
NUT, SELF LOCKING (1M1)
901851207200
|
4,21 € | 1 | Add |
| 10 |
BOLT, WASHER BASED (2H7)
901051010500
|
7,19 € | 1 | Add |
| 11 |
BOLT, FLANGE
901051017400
|
10,44 € | 1 | Add |
| 12 |
NUT, SELF-LOCKING(3KJ)
901851015400
|
3,65 € | 1 | Add |
| 13 |
BRACKET, RADIATOR
37PF142M0000
|
70,03 € | 1 | Add |
| 14 |
NUT, FLANGE
9570N0650000
|
Obsolete | 10 | Not available |
| 15 |
CLIP 1
5MFE24860000
|
6,68 € | 1 | Add |
| 16 |
APOYAPIE POSTERIOR 1
5WXF74310100
|
32,40 € | 1 | Add |
| 17 |
SPRING, COMPRESSION (22N)
905011274300
|
5,07 € | 5 | Add |
| 18 |
BALL
935010401100
|
0,39 € | 5 | Add |
| 19 |
PIN, COTTER (E57)
914901602000
|
5,31 € | 1 | Add |
| 20 |
COLLAR (24R)
90387064H800
|
4,36 € | 5 | Add |
| 21 |
PIN, WITH HOLE (465)
902400604200
|
5,46 € | 1 | Add |
| 22 |
APOYAPIE POSTERIOR 2
5WXF74410100
|
32,40 € | 1 | Add |
| 23 |
SPRING, COMPRESSION (22N)
905011274300
|
5,07 € | 5 | Add |
| 24 |
BALL
935010401100
|
0,39 € | 5 | Add |
| 25 |
PIN, WITH HOLE (465)
902400604200
|
5,46 € | 1 | Add |
| 26 |
PIN, COTTER (E57)
914901602000
|
5,31 € | 1 | Add |
| 27 |
COLLAR (24R)
90387064H800
|
4,36 € | 5 | Add |
