Yamaha 50cc SCOOTERS Bw's 50 2006
Add model to garageFRONT FORK Yamaha Bw's 50 2006
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
FRONT FROK ASSY
5FXF31000200
|
411,54 € | 1 | Add |
| 2 |
INNER TUBE COMP.1
5FXF31100000
|
Obsolete | 1 | Not available |
| 3 |
OUTER, TUBE 2
5FXF31360000
|
Obsolete | 1 | Not available |
| 4 |
TUBE, OUTER 1
5FXF31260000
|
160,38 € | 1 | Add |
| 5 |
UNDER, BRACKET COMP.
5BRF33400200
|
162,61 € | 1 | Add |
| 6 |
RING, SNAP
4TDF31530000
|
Obsolete | 1 | Not available |
| 7 |
PLUG, INNER TUBE
4TDF31540000
|
Obsolete | 1 | Not available |
| 8 |
WASHER, CAP
4TDF31120000
|
Obsolete | 1 | Not available |
| 9 |
BOLT, SPECIAL
4TDF33940000
|
Obsolete | 1 | Not available |
| 10 |
CIRCLIP
4TDF31830000
|
Obsolete | 1 | Not available |
| 11 |
O-RING
4TDF31470000
|
Obsolete | 1 | Not available |
| 12 |
BOLT, CAP
4TDF31110000
|
14,95 € | 1 | Add |
| 13 |
SEAL, DUST
4TDF31440000
|
Obsolete | 1 | Not available |
| 14 |
CLIP, OIL SEAL
4TDF31560000
|
Obsolete | 1 | Not available |
| 15 |
OIL SEAL
4TDF31450000
|
25,59 € | 1 | Add |
| 16 |
SPRING, FRONT FORK
4TDF31410000
|
20,76 € | 1 | Add |
| 17 |
WASHER, FELT
4CUF31650000
|
Obsolete | 1 | Not available |
| 18 |
BOLT, HEXAGON SOCKET HEAD
4TDF31810000
|
Obsolete | 1 | Not available |
| 19 |
EMBLEM
5BRF31080000
|
Obsolete | 1 | Not available |
| 20 |
SPARE PART
4SBF34110200
|
7,89 € | 1 | Add |
| 21 |
RACE, BALL 4
4SBF34140000
|
8,65 € | 1 | Add |
| 22 |
RACE, BALL 2
4SBF34120000
|
Obsolete | 1 | Not available |
| 23 |
PLANE BEARING, STEERING
4SBF38120000
|
8,30 € | 1 | Add |
| 24 |
WASHER
4SBF34270100
|
Obsolete | 1 | Not available |
| 25 |
NUT
9017925X0000
|
Obsolete | 5 | Not available |
| 26 |
REFLECTOR
5HEH51110000
|
12,20 € | 1 | Add |
