Yamaha 50cc SCOOTERS Bw's 50 2006
Add model to garageFUEL TANK Yamaha Bw's 50 2006
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
FUEL TANK + SENDER ASSY
5FXWF4110200
|
Obsolete | 1 | Not available |
| 2 |
SENDER
5FXH57520100
|
Obsolete | 1 | Not available |
| 3 |
NUT, SPRING
9018304X0000
|
7,39 € | 1 | Add |
| 4 |
CAP ASSY
4MJF46100000
|
18,54 € | 1 | Add |
| 5 |
BOLT, WASHER BASED
9010506X0200
|
Obsolete | 1 | Not available |
| 6 |
COLLAR(47X)
90387060G700
|
1,60 € | 5 | Add |
| 7 |
WASHER, PLATE
902010638000
|
1,55 € | 1 | Add |
| 8 |
SEAL
5ADF414G1000
|
11,96 € | 10 | Add |
| 9 |
GROMMET
904801301400
|
2,35 € | 1 | Add |
| 10 |
DAMPER
4SBF174X1000
|
10,81 € | 1 | Add |
| 11 |
GRIFO DE COMBUSTIBLE 1
1PHF45000000
|
45,83 € | 1 | Add |
| 12 |
FILTER
5EUF45010000
|
Obsolete | 1 | Not available |
| 13 |
O-RING
5EUF45120000
|
Obsolete | 1 | Not available |
| 14 |
HOSE CLAMP ASSY
9045022X0300
|
Obsolete | 1 | Not available |
| 15 |
PIPE ,2
4SBF43123100
|
Obsolete | 1 | Not available |
| 16 |
PIPE,SUCTION 1
4SBF43353100
|
Obsolete | 1 | Not available |
| 17 |
CLIP
90467090A200
|
0,74 € | 1 | Add |
