Yamaha MAXI SCOOTERS T-Max 530 ABS 2013
Add model to garageSIDE STAND Yamaha T-Max 530 ABS 2013
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 28 |
BOX 2
59C2838L0000
|
24,19 € | 1 | Add |
| 29 |
PIN, LOCK
59C282350000
|
1,87 € | 1 | Add |
| 30 |
COVER, LOCK
59C2848Y0000
|
3,75 € | 1 | Add |
| 31 |
SPRING
59C283880000
|
2,41 € | 1 | Add |
| 32 |
SCREW, TAPPING(4TV)
901670507700
|
0,62 € | 5 | Add |
| 33 |
PLUG(1NL)
903380718000
|
6,85 € | 5 | Add |
| 34 |
PLUG (17J)
903381013200
|
3,18 € | 1 | Add |
| 35 |
DAMPER, PLATE
905200600300
|
1,54 € | 1 | Add |
| 36 |
SPRING 2
59C2838C0000
|
2,61 € | 1 | Add |
| 37 |
NUT, SPRING(4ES)
901830606900
|
2,12 € | 1 | Add |
| 38 |
DAMPER, SEAT
59C247240000
|
6,42 € | 1 | Add |
| 39 |
DAMPER, LOCATING 1
5JX217780000
|
1,68 € | 1 | Add |
| 40 |
BOLT, WITH WASHER
901190624200
|
1,72 € | 1 | Add |
| 41 |
LOCK SET 2
59C284070000
|
131,61 € | 1 | Add |
| 42 |
STAY, LOCK
59C2117K0000
|
3,74 € | 1 | Add |
| 43 |
SPRING, LOCK 2
59C2176V0000
|
11,09 € | 1 | Add |
| 44 |
SCREW, TAPPING(4TV)
901670507700
|
0,62 € | 5 | Add |
| 45 |
RIVET
902690300100
|
1,60 € | 1 | Add |
| 46 |
PANEL, INNER 1
59C2836K0000
|
166,09 € | 1 | Add |
| 47 |
SCREW, TAPPING(4TV)
901670507700
|
0,62 € | 5 | Add |
| 48 |
DAMPER, PLATE
905200301200
|
2,01 € | 1 | Add |
| 49 |
RIVET
902690600100
|
1,60 € | 1 | Add |
| 50 |
BOLT
901110500200
|
1,37 € | 1 | Add |
| 51 |
NUT, SPRING(1YT)
901830504200
|
0,62 € | 5 | Add |
| 52 |
PANEL, ACCESSORY
59C2839R00P0
|
105,07 € | 1 | Add |
| 53 |
CUERPO, CARENADO
59C2835101P1
|
201,69 € | 1 | Add |
| 53 |
CUERPO, CARENADO
59C2835101P3
|
201,69 € | 1 | Add |
