Yamaha SPORT TOURING FJR1300AS 2011
Add model to garageWATER PUMP Yamaha FJR1300AS 2011
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
HOUSING, WATER PUMP
5JW124211000
|
197,36 € | 1 | Add |
| 2 |
BRG,R-B 6001 28MM 28G KY
933060010500
|
16,95 € | 1 | Add |
| 3 |
OIL SEAL
931021237200
|
7,01 € | 1 | Add |
| 4 |
SEAL, MECHANICAL
11H124381000
|
54,63 € | 1 | Add |
| 5 |
IMPELLER SHAFT ASSY
5JW124500000
|
172,90 € | 1 | Add |
| 6 |
COVER, HOUSING
5JW124221000
|
209,90 € | 1 | Add |
| 7 |
O-RING
5JW124390000
|
26,16 € | 1 | Add |
| 8 |
BOLT, FLANGE
901050606500
|
2,12 € | 1 | Add |
| 9 |
BOLT, FLANGE(4KG)
950240602500
|
1,46 € | 1 | Add |
| 10 |
GASKET 256113960000
904300601400
|
2,33 € | 1 | Add |
| 11 |
CIRCLIP(10Y)
990091240000
|
1,82 € | 1 | Add |
| 12 |
O-RING (626)
932103313300
|
4,40 € | 1 | Add |
| 13 |
BOLT, HEXAGON SOCKET HEAD
901100633600
|
2,55 € | 1 | Add |
| 14 |
BOLT, HEXAGON SOCKET HEAD
901100633700
|
4,65 € | 1 | Add |
| 15 |
HOSE 1
5JW125760000
|
25,23 € | 1 | Add |
| 16 |
HOSE CLAMP ASSY(3GM)
904503804000
|
18,74 € | 1 | Add |
| 17 |
COVER 2
5GV1246E0000
|
6,65 € | 1 | Add |
| 18 |
JOINT, HOSE 1
3P6125810000
|
66,00 € | 1 | Add |
| 19 |
HOSE 2
5JW125770000
|
28,93 € | 1 | Add |
| 20 |
HOSE CLAMP ASSY(3GM)
904503804000
|
18,74 € | 1 | Add |
| 21 |
JOINT 1
5JW124690000
|
64,48 € | 1 | Add |
| 22 |
O-RING(52H)
932104767500
|
3,42 € | 1 | Add |
| 23 |
BOLT, FLANGE
950220602000
|
0,52 € | 1 | Add |
| 24 |
PIPE 1
3P6124810200
|
188,87 € | 1 | Add |
| 25 |
O-RING (716)
932101841700
|
4,40 € | 5 | Add |
| 26 |
BOLT,SOCKET
913170601600
|
0,28 € | 1 | Add |
| 27 |
HOSE 3
3P6125780000
|
24,09 € | 1 | Add |
