Yamaha CARRETERA WR250X 2014
Add model to garageFRONT FORK Yamaha WR250X 2014
| Pos. | Ref./Description | Price | Qty. | |
|---|---|---|---|---|
| 1 |
FRONT FORK ASSY (L.H)
32D231028000
|
952,63 € | 1 | Add |
| 2 |
OUTER TUBE COMP. (L.H)
3D7231063000
|
484,47 € | 1 | Add |
| 3 |
RING, SNAP
3D7231530000
|
4,69 € | 1 | Add |
| 4 |
INNER TUBE COMP.1
3D7231101000
|
467,70 € | 1 | Add |
| 5 |
PISTON, FRONT FORK
5ET23171L000
|
19,27 € | 1 | Add |
| 6 |
METAL, SLIDE 1
5ET23125L000
|
19,27 € | 1 | Add |
| 7 |
WASHER, OIL SEAL
5UN23146L000
|
11,15 € | 1 | Add |
| 8 |
OIL SEAL
5UN23145L000
|
20,33 € | 1 | Add |
| 9 |
RING, SNAP
4SS23153L000
|
4,42 € | 1 | Add |
| 10 |
SEAL, DUST
5HD23144L000
|
41,49 € | 1 | Add |
| 11 |
CYLINDER COMP., FRONT FORK
32D231700000
|
912,26 € | 1 | Add |
| 12 |
VALVE COMP.
32D2316A1000
|
492,06 € | 1 | Add |
| 13 |
O-RING
4DA23147L000
|
7,66 € | 1 | Add |
| 14 |
EMPAQUE
276231140100
|
4,84 € | 1 | Add |
| 15 |
GASKET
2HH23158L000
|
5,41 € | 1 | Add |
| 16 |
GUIDE, SPRING
3D7231170000
|
48,51 € | 1 | Add |
| 17 |
NUT
3XJ23357L000
|
0,74 € | 1 | Add |
| 18 |
SPRING, FRONT FORK
32D231410000
|
97,70 € | 1 | Add |
| 19 |
SEAT, SPRING LOWER
4SS23143L000
|
16,94 € | 1 | Add |
| 20 |
BOLT, CAP
3D7231110000
|
363,38 € | 1 | Add |
| 21 |
O-RING
3D7231470000
|
4,57 € | 1 | Add |
| 22 |
PLUG
3JD2312GL000
|
7,26 € | 1 | Add |
| 23 |
BOLT, FLANGE
950220804000
|
0,46 € | 1 | Add |
| 24 |
FRONT FORK ASSY (R.H)
32D231038000
|
952,63 € | 1 | Add |
| 25 |
OUTER TUBE COMP. (L.H)
3D7231063000
|
484,47 € | 1 | Add |
| 26 |
RING, SNAP
3D7231530000
|
4,69 € | 1 | Add |
| 27 |
INNER TUBE COMP.2
3D7231201000
|
467,70 € | 1 | Add |
